Leviton Type 2 Surge Protective Panel, 480Y/277-Volt AC, 3-phase WYE, 130kA per Phase B3277-YB

B series Type 2 Surge Panel, 480Y/277 Volt AC, 3-phase WYE, Max Surge Current Rating of 65kA per Mode/130kA per Phase, 200kA Short Circuit Current Rating (SCCR), 20kA I-nominal (ln) Rating, NEMA 4X Rated Enclosure. Thermally Protected MOVs, VPR Performance Data equal to L-N: 1200, L-G: 1200, N-G: 1200, L-L: 2500, Maximum Continuous Operating Voltage (MCOV): 350-Volt/700-Volt, Plastic Enclosure. LED Status Monitoring, Audible Alarm, UL 1449 Listed, UL 1283 EMI/RFI Filtering.

• SPDs divert damaging surges away from electronic equipment
• Ideal for the branch panel in commercial/industrial applications
• Ideal for the main panel in light commercial applications
