SKU CE7051

Campbell Hausfeld 80 Gal. Electric Air Compressor

The Campbell Hausfeld 80 Gal., 5 HP, vertical, 2-stage air compressor (CE7051) is ideal for auto repair facilities and tire repair outlets. This air compressor has a high air flow of 17.2 CFM at 90 PSI to power air tools. Operating on three-phase electric power, its rugged motor drives a long-life, cast-iron, 2-stage pump that's designed to deliver more than 15,000 hours of operation. The pump head and valve plate feature an advanced design with Viton(r) high-temperature O-rings for superior high-pressure sealing when compared to paper gaskets. For smooth, low-vibration operation, the crankshaft is fabricated of ductile iron and optimally balanced.

High air flow & tank size to power multiple high-demand air tools
2-stage pump made to deliver more than 15,000 hours of operation
Ideal for auto repair facilities and tire repair outlets

Specifications

Model #: CE7051
Portable: No
Internet #: 202959348
Phase Type: 3 Phase
Power Type: Corded Electric
Returnable: 90-Day
Tank Style: Vertical
Stage Count: Two Stage
Store SKU #: 1000469258
Voltage: 208-230/460 V
Amperage: 14 A
Power Source: Electric
Application Use: Air Brushing,Blow Cleaning,Bolting,Brad Nailing,Cutting,Drilling,Finish Nailing,Framing Nailing,Grinding,HVLP Painting,Inflation,Sanding,Spraying,Stapling,Surface Prep,Wrenching
Compressor Type: Industrial
Horsepower: 5 hp
Lubrication Type: Oil
Tools Product Type: Air Compressor
Product Depth: 35 in
Product Width: 42 in
Product Height: 78 in
Product Weight: 540 lb
Manufacturer Warranty: 3 year limited
Maximum Pressure: 200 PSI
Compressor Volume Rating: Standard
Decibel Rating: 85 dBA
Air Delivery SCFM @ 40PSI: 16.7
Air Delivery SCFM @ 90PSI: 17.2
Compressor/Air Tool Features: Tank Pressure Gauge
Compressor Tank Capacity: 80 gal
Number of Total Batteries Included: 0
